Fully Automatic Powder Granule Pellet Capsules Filler Capsule
Filling Machine
Product Description
Main features:
1. Touching-Screen, PLC program control panel with LCD.
2. Capsule vacuum positioned mechanism to make the capsule
qualified over 99%.
3. Removable powder hopper for cleaning and easy auger adjustment
easy to change fills weights.
4. Easy speed selection and closed capsule length adjustment.
5. Electrical Appliance control system approved to CE, and
international standard.
6. Quick and accurate change part set-up, easy to remove rotary
table and ring carrier assembly.
7. Fully enclosed dosing stations and rotating table for
integration of the whole capsule filling plants.
8. Large cam mechanism keeps the rotating table of mold together
with the whole equipment running with balance, and completely
guarantees the machine operating with highest precision and
accuracy.
Main technical parameters:
| Model | XY-200D | XY-400D |
| Capacity | 200 capsules/min. | 400 capsules/min. |
| Filling type | Powder, Granule | Powder, Granule |
| No. of mold holes | 2 | 3 |
| Applicable capsule model | 00#, 0#, 1#, 2#, 3#, 4# | 00#, 0#, 1#, 2#, 3#, 4# |
| Filling accuracy | ±3%-±4% | ±3%-±4% |
| Noise | ≤75dB(A) | ≤75dB(A) |
| Voltage | 380V 50Hz 3P | 380V 50Hz 3P |
| Total power | 3.75Kw | 3.75Kw |
| Net weight | 600Kg | 600Kg |
| Gross weight | 650Kg | 650Kg |
| Machine size | 750mm(L)x680mm(W)x1700mm(H) | 750mm(L)x680mm(W)x1700mm(H) |
| Package size | 1600mm(L)x1050mm(W)x1900mm(H) | 1600mm(L)x1050mm(W)x1900mm(H) |
Company introduction
Zhejiang Xingyi Technology Co., Ltd is a professional machinery
equipment manufacturer located in Henan Province, China. The
company specializes in the production, processing and sales of food
machinery, agricultural machinery and other machinery. We mainly
cover the production scope: snack food processing machinery, candy
processing machinery, fruit and vegetable processing machinery,
printers, packaging machinery, water well drilling machine, various
peeling machines.
The company covers an area of 10,000 square meters, with fixed
assets of 50 million yuan. There are more than 100 employees, more
than 30 technical personnel, and more than 100 sets of various
production equipment. Equipment includes: large press machine,
digital lathe, digital wire electrode cutting equipment, all kinds
of processing machinery and equipment. The company has national
patents and proprietary technology, with independent research and
development capabilities.
After-sales Service
1 24 hour communication service
2 Fast logistics will provide you a smooth delivery service
3 One-year warranty and lifetime technical support
4 New design or product recommendation
5 Attend international Fair to negotiate with customer face to face
6 offer official invitation if you come to China
7 Reception service,help you to book good hotel
FAQ
Q1 :What's your company after-sales service?
A1: We will check three times before shipment to ensure that the
machine itself has no problems.Offering the best quality
machine&the best service to our customers is the mission of our
enterprise.
Q2 :Any warranty ?
A2:One year warranty. Frankly speaking, the quality of our machines
is very stable. The machine will be checked three times before
leaving the factory to ensure that you can receive the machine in
the best condition. If you have any questions, we can make a video
call at any time.
Q3: How to transport without customs clearance experience ?
A3:We have reliable forwarder agent which can ship items to you by
sea/air/Express to your home. We will help you choose the most
suitable shipping service.
Q4: Differences from other brands in China ?
A4:We are not only selling machines, we pay more attention to
after-sales service. We have always believed that the customer's
reputation is the best advertisement.
We hope to really help our customers use machines and bring growth
to their business. You can view our customers' feedback, facts
speak louder than words.
Q5 :Can I print my logo on the machine ?
A5: Yes, sure. We can provide professional customized logo services
for customers.
Q6 :How does your factory do regarding quality control?
A6: Quality is priority. We always attach great importance to
quality control from the very beginning to the end of the
production. Every product will be fully assembled and carefully
tested before it's packed for shipment.
